Chicken wire is mainly used in farms for breeding of chicken and other fencing uses. Supplied in mesh rolls and fabricated mesh cages.
Corrosion treaments:
Eelectro galvanized
Hot dipped galvanised
Bonded pvc / vinyl coating + zinc galvanizing
Hole type: Hexagonal
Process: Twist woven, galvanized after weave, or galvanized before
Fabric Edges:
Single selvage
Double selvage
Reinforced edge
Applications:
Chicken Coops
Chicken Fencing
Poultry Enclosures
Rabbit netting
Garden fencing
Our Capabilites
Mesh: 2" Hexagonal hole wire net
Galvanized after reverse twisted weaving
Wire: 20 Gauge
Surface: Hot dip zinc coating
Roll: 72" x 150"
Mesh: 1 inch hexagonal hole wire net
Plastic coated galvanised after weaving
Mesh rolls: 2 meters (6 feet) x 100 feet
2m / 6 feet x 150 feet
To Canada
Wire: 18 gauge
Mesh:
1” hex
Rolls size:48” x 100’, 48" x 150’
Surface: Black vinyl coating
Mesh: 2 inch hexagonal hole netting
Gauge: 20
Surface: Galv. and vinyl powder coating
Color:
Green vinyl coated
Rolls:18” x 150’
Protection fencing uses
Vinyl coated wire fencing mesh: 1 inch hexagonal twist woven wire
Gauge: 20 gauge core wire, 18 gauge with vinyl coating layer.
Surface: Vinyl / polyester / pvc bonded coating
Color: Black vinyl coated
Rolls:
18 by 150 feet
Material: Galvanized chicken wire
Roll size:48”X150’
Hole size: 1 inch
Finish: Black PVC coated
Mesh: 1/2 inch twist woven wire mesh
Wire material: PVC Coated GI Wire
Wire gauge: 1.5mm / 2.5mm( Inner Diameter Gi wire / Diameter PVC Coated )
Wire gauge: 2.8mm / 4mm( Inner Diameter Gi wire / Diameter PVC Coated )
Wire gauge: 3.4mm / 4.75mm( Inner Diameter Gi wire / Diameter PVC Coated )
Mesh: 20mm Diamond Shape
Wire gauge: 18 gauge
Size : 1219mm x 30 m
Form of supply: Mesh rolls
Colour: white
Wire mesh roll: 30 meter x 10 meter
Common size for Malaysia market:
Specifications of Hexagonal Chicken Wire Mesh |
||||||
| Specifications | Wire Gauge | Roll Width | ||||
| Mesh (inch) | Size No (mm) | Tolerance | British System Gauge No | Wire Diameter in mm | British system | Metric System |
| 3/8" | 10 | +0.5 | BWG 27-23 | 0.41 - 0.64mm | 1' - 6' | 0.1 - 2 m |
| 1/2" | 13 | -1.5 | BWG 27-22 | 0.41 - 0.71mm | 1' - 6' | 0.1 - 2 m |
| 5/8" | 16 | +1.0 / -2.0 | BWG 27-22 | 0.41 - 0.71mm | 1' - 6' | 0.1 - 2 m |
| 3/4" | 19 | +1.0 / -2.5 | BWG 26-20 | 0.46 - 0.89mm | 1' - 6' | 0.1 - 2 m |
| 1" | 25 | +1.5 | BWG 25-29 | 0.51 - 1.07mm | 1' - 6' | 0.1 - 2 m |
| 1.25" | 31 | -3.0 | BWG 24-18 | 0.56 - 1.24mm | 1' - 6' | 0.2 - 2 m |
| 1.5" | 40 | +2.0 / -4.0 | BWG 23-16 | 0.64 - 1.65mm | 1' - 6' | 0.2 - 2 m |
| 2" | 51 | +2.0 / -4.0 | BWG 22-14 | 0.71 - 2.11mm | 1' - 6' | 0.2 - 2 m |
| 3" | 76 | +2.0 / -4.0 | BWG 21-14 | 0.81 - 2.11mm | 1' - 6' | 0.3 - 2 m |
| 4" | 100 | +2.0 / -4.0 | BWG 20-12 | 0.89 - 2.8mm | 1' - 6' | 0.5 - 2 m |
| Max. roll width: 2m. Customized sizes available. | ||||||
We also supply welded mesh and plastic extruded mesh for chicken fencing uses.
